Lazarus Track Hubs Raptor

Lighter than Jesus toga and stiffer than Devils horn .

Completely CNC machined and carefully assembled by hands of your humble servants from LAZARUS team in Kiyv, Ukraine.

Intelligent construction in combination with precision Japanese bearings and certified aluminium alloys won't let the chance to your opponents on track and roads.

LBPS(LAZARUS Bearing Preload System) gives you opportunity to adjust your hubs directly on the bike with 2.5mm hex key.

- exceptionally rational construction let us achieve amazing 395 GRAM per hubset

- increased left flange diameter on rear hub for higher lateral stiffness and equal spoke length

- bearings guards protect from dust for long life without maintenance

- inclined flanges to prevent spokes overbending

- metal shielded bearings for indor or rubber sealed bearings for outdoor races

TECHNICAL DATA

1.37×24tpi cog  and 1.24×24tpi lockring thread
15mm extra stiff axle
M8 hexagon socket head axle bolts
6902 NTN bearings
2.5mm spoke hole diameter
rear hub O.L.D.-120mm, front hub O.L.D.-100mm

HUB DIMENSIONS
