Oltre Race 105 Neues Modell 2024 Vororder bitte per Mail

Von Bianchi

SFr. 3,399.00

Neu Session 2024

TECH SPECS

  • FRAMESET
    1. FRAMEOltre Race aero carbon, compatible with mechanical/electronic transmissions, compatible with internal cable routing, BB-PressFit 86,5x41, integrated seat clamp, disc brake flat mount, thru axle 12x142 sizes 44-47-50-53-55-57-59-61cm
    2. FORKFull Carbon Aero Road, integrated head , disc brake flat mount, thru axle 12x100
    3. HEADSETACROS & FSA, for internal cable routing
  • DRIVETRAIN
    1. SHIFTERSShimano 105 hydraulic disc brake for road for 160mm rotor
    2. REAR DERAILLEURShimano 105
    3. FRONT DERAILLEURShimano 105
    4. CRANKSETShimano, 105, hollowtech 2, 50x34T, Crank Length: 165mm-44cm, 170-47/53cm, 172.5mm-55/59cm, 175mm-61cm
    5. BOTTOM BRACKETShimano, SM-BB72-41B, press fit for road
    6. CHAINShimano
  • BRAKES
    1. BRAKESShimano, Hydraulic disc brake, included in the shifter
    2. ROTORShimano rotor for disc brake center lock, 160mm
  • WHEELS
    1. WHEELSFulcrum Racing 818 disc brake, Aluminium C19 2WF-R Tubeless ready 622x19c, profile height 34mm, HG11
    2. TIREVittoria Rubino IV G2.0 graphene, 700x28, 60TPI
  • COCKPIT
    1. STEMVelomann, Alloy 6061, raise - 7° Ext: 80mm-44cm, 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59/61cm
    2. HANDLEBARVelomann Aero Compact, alloy 6061 diam. 31,8mm, reach 74mm, drop 116mm Size: 400mm-47/53cm, 420mm-55/59cm, 440mm-61cm
    3. GRIPSBianchi cork, black
  • SADDLE
    1. SEATPOSTVelomann Full Carbon Aeroshape, special Clamp type with alloy head adjustable and reversible +/- 35mm; lenght: 250mm-44, 300mm-47/50cm, 350mm-53/61cm

SIZE A B C D E F G G1 H I X Y WB
440 420 505 410 58 95 575 75° 70.5° 43 368 376 481 977
470 440 515 410 58 105 581 74.5° 70.5° 43 368 379 490 982
500 470 525 410 58 110 582 74.5° 71.5° 43 368 387 499 983
530 500 535 410 68 125 583 74° 72° 43 368 385 525 984
550 520 550 410 68 140 588 73.5° 72.5° 43 368 390 541 988
570 540 560 410 68 155 593 73.5° 73° 43 368 395 557 994
590 560 575 412 68 175 603 73° 73° 43 368 397 576 1006
610 580 585 414 68 195 607 72.5° 73° 43 368 398 595 1012
